Hyundai Excavator 31N6-10140 31N6-10130 Swing Motor for R210-7 R215-7 R220-5 Slewing Motor Assy

Original OEM swing motor assembly compatible with Hyundai excavator models R210-7, R215-7, and R220-5.

Product Specifications

Component Parts List

#	Part No	Part Name	Qty.
N*	31N6-10130	SWING MOTOR ASSY	1
*-1	31N6-10140	SWING MOTOR UNIT	1
1	XJDB-00002	RACE-INNER	1
2	XJDB-00003	SEAL-OIL	1
3	XJDB-00004	BEARING-ROLLER	1
4	XJDB-00005	SPRING-BACKING	1
5	XJDB-00006	PLATE-CAM	1
6	XJDB-00007	PLATE-RETURN	1
7	XJDB-00008	PISTON ASSY	9
8	XJDB-00009	PLATE-LINING	3
9	XJDB-00010	PLATE	3
10	XJDB-00011	O-RING	1
11	XJDB-00012	PISTON	1
12	XJDB-00013	O-RING	2
13	XJDB-00014	SPRING	15
14	XJDB-00015	PIN-PARALLEL	2
15	XJDB-00016	PISTON	2
16	XJDB-00017	CAP	3
17	XJDB-00018	O-RING	3
18	XJDB-00019	SCROWWAVE	4
19	XJDB-00020	RING-TEFLON	4
20	XJDB-00021	BUSHING	4
21	XJDB-00022	PLATE-BALANCE	1
22	XJDB-00023	BEARING-NEEDLE	1
23	XJDB-00024	RING-SNAP	1
N24	XJDB-00025	CYLINDER ASSY	1
N25	XJDB-00026	HOUSING	1
26	XJDB-00027	COLLAR	1
27	XJDB-00028	PLUG	1
28	XJDB-00029	RING-SNAP	1
29	XJDB-00030	BYPASS VALVE ASSY	2
30	XJDB-00031	RING-BACK UP	2
31	XJDB-00032	O-RING	2
32	XJDB-00033	O-RING	2
N33	XJDB-00034	COVER	1
34	XJDB-00035	RELIEF VALVE ASSY	2
35	XJDB-00036	O-RING	4
36	XJDB-00037	BOLT-SOCKET	3
